Zero downtime migration of Azure Kubernetes clusters managed by Terraform

For me, that kind of resource was Kubernetes cluster and its default node pool, which we run in Azure. As it turns out, when you try to change the size of VMs used by it, your azurerm provider forces you to recreate the whole cluster (together with dependent resources). That is something that you would usually like to avoid doing, especially in production. Even though I will be focusing on the Azure Kubernetes Service in this article, I am positive that you could modify this technique to be usable with other resources as well.

Let’s say that your cluster has grown out of some small VMs that you’ve put there in the beginning. The first thing that you’d try to do is change the vm_size in the terraform configuration and apply it. This is when you get the following situation:

If you are attentive, that is. Otherwise you might have just written „yes“ losing your instance together with your deployments, secrets and whatever kind of data you might have been storing there. Also, you might know that Kubernetes clusters are not provisioning very quickly, so we can be looking at a downtime of 1.5-2hrs from my experience.

Moreover, you could have just lost something that was depending on your terraform configuration, like this poor little public IP address:

This might cause even more trouble if you have your allow lists unmanaged by terraform, or just have some third parties who explicitly allow your IPs.

There is no way we should tolerate this kind of outages in the modern world where organisations are focused on being available 99.9% of a time. So, let’s see how we can mitigate such an annoyance!

There are several possible solutions one can apply in order to keep their resources intact. Amongst the most obvious ones are:

• Keep default node pool while creating separate ones of required size,

• Manually migrate to a new node pool using a temporary one.

Both of those options rely on the ability to create non-default node pools in AKS, which is a relatively new AKS feature, so it’s going to be interesting to have a look at how we can use it to our benefit.

A method that is somewhat more painful, but still preferable if you want to keep your infrastructure simple, is to create a new node pool and move your pods to it, deleting the old one.  Let me walk you through the steps needed to achieve it.

First things first: we need a new agent pool for it to host our pods. I recommend you first get the details of your existing default pool so that when you apply your changes in terraform, the cluster does not get recreated. You can get them by running this command:

> az aks nodepool show –cluster-name $YOUR_CLUSTER_NAME –resource-group $RESOURCE_GROUP_NAME –name agentpool

Which is going to produce something like this:

I’ve highlighted with green which properties we need to preserve in order to make this migration seamless. In red there is the value that we are going to change. Coincidentally, most of those values are not changeable while the cluster is running, so you might also use this technique to change the other highlighted values – just remember to update them in terraform.

With those values in mind, we can create a new node pool for the migration:

> az aks nodepool add –cluster-name $YOUR_CLUSTER_NAME -g $RESOURCE_GROUP_NAME -n agentpool1 –node-vm-size Standard_A4_v2 –node-count 3 –mode System -z 1 2 3 –node-osdisk-size 30

You can see that highlighted values are all there, except the one we are going to change (Standard_A4_v2) and the agent pool name. That name is changed because Kubernetes won’t allow us to have multiple pools with the same name. In order to preserve the name, we’re going to repeat the same procedure after we delete the original agentpool. Alternatively, we can change the name in our terraform definition, which should work just fine, unless you have some taints based on the pool name.

In order to perform this migration with no downtime at all (or if you have disruption budget specified for your applications) you’d have to have at least two pods of each of your applications at the same time (if it is supported). If you scale up your number of replicas, I recommend using:

> kubectl cordon -l agentpool=agentpool

before changing it. This should prevent pods from being scheduled on our old agentpool.

Now we can evict pods from our old agent pool:

> kubectl drain -l agentpool=agentpool

If your pods don’t use local storage or DaemonSets, this should be enough. In my case, I had to add two more parameters and do the following:

> kubectl drain -l agentpool=agentpool –delete-local-data –ignore-daemonsets

I didn’t find a way to preserve local data, unfortunately, but in the majority of cases it’s going to be just some cache. You should verify this going in, however.

If you still get exceptions like the ones that you see below (from istio in my case), you might need to verify that pods with disruption budget are having enough replicas configured.

Finally, we can delete our old node pool from the cluster:

> az aks nodepool delete –name agentpool -g $RESOURCE_GROUP_NAME –cluster-name $YOUR_CLUSTER_NAME

I was surprised to find out that my continuously running postman test checking liveness of one of the endpoints only failed during this step, even though there were no replicas running for that application:

That being the only outage during the whole process, I can say that the migration was quite successful, but we have just a few more things to do.

There are two ways we can go from here:

• Repeat the steps above to preserve the name of our default agent pool („agentpool“ in my examples),
• Leave it as is („agentpool1“) and just change it in terraform.

For the purposes of this article, I would go with the second option, which should suffice if you don’t have pool name tolerations set for your pods. You can practice the first option, since it’s basically the same steps, but with different names.

For that to work, we need to update our terraform definitions. You’ll have to find the line that looks like this:

and change the value to „agentpool1“ (or some other name that you’ve chosen). If we apply our changes now, however, terraform is going to force recreation of our cluster (so much for all that work!), since an old state is cached and it can’t associate the cluster with our new node pool to what is in the state. We need to reimport our cluster. I like using:

> terraform state list | grep kubernetes_cluster

In order to find out the complete resource name, but if your definitions are rather simple, you can just type the name in. Regardless of which approach you prefer, we should now delete it from the state. Please note that if you have other Kubernetes resources (like namespaces or secrets) created in terraform, you’d need to reimport them as well. When reimporting, take care when specifying the id of the resource – it should be the same as it was in its state previously (terraform is case-sensitive!).

> terraform state rm $K8S_RESOURCE_NAME && terraform import $K8S_RESOURCE_NAME „/subscriptions/$subscriptionId/resourcegroups/$rg_name/providers/Microsoft.ContainerService/managedClusters/$cluster_name“

After we’ve done this, terraform is going to „get used“ to a new node pool and just go with it if we do terraform apply:
